Miter Stone Cutting Machine

Name: Miter Stone Cutting Machine
Brand: StoneSawMachine.com
Price: 1 USD

Brand Name : StoneSawMachine.com

Model Number : MCJL-625

Certification : CE,ISO9001

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, , T/T

Supply Ability : 20 Sets Per Month

Delivery Time : 30 days after deposit

Packaging Details : Plastic FIlm

Voltage : 380/220/415V,3ph

Weight : 6400kg

Use : granite and marble

Condition : New

Dimension(l*w*h) : 6000×5700×3600

Type : Stone Cutting Machine,Bridge Saw

Warranty : 1 Year

Control system : PLC SYSTEM

Product name : Miter Stone Cutting Machine

Color : customized

Motor : Stepper motor

Application : Stone Industrial

Spindle : 13kw

Blade diameter : 400-625mm

Function : STONE CUTTING,marble/granite edge cutting machine

Keyword : Stone cutting machine,CNC Marble Cutting Machine

Contact Now

Miter Stone Cutting Machine

1) Monoblock structure for easy transport, installations and no foundation needed.

2) Siemens, Schneider electric and other high quality accesories such as Hiwin linear guide are adopted.

3) 0°, 90°, 180° and 270° automtaic head rotatation and blade positioning.

4) Blade can tilt 45° automtically for chamfering cutting.

5) Automatic cross cutting repeatedly so easy by pushing one-button.

6) Manual cuts available for simple machining

7) Worktable can rotate 0-360°, pause at every 45° automatically or stop at any degree by remote control.

8) Worktable can tilt 0-85°, easy for slab loading.

Appellation	MCJL-625
Max.blade diameter (mm)	Φ700
Max.liftingl sroke (mm)	470
Worktable size (mm)	3200×2000
Blade tilt range (°)	0- 50
Worktable rotation range(optional) (°)	0°- 90°/0°- 360° (Set up by each 45° degree)
Worktable turn-over degree (°)	85
Water consumption (m³/h)	3
Power of main motor (kw)	18.5
Total power (kw)	25
Dimension (mm)	6000×5700×3600
Weight (kg)	6400(With stand 7500kg)

Miter Stone Cutting Machine

Product Tags:

45 degree stone miter saw

head tilting bridge saw machine

miter stone saw machine

Wholesale Miter Stone Cutting Machine from china suppliers

Miter Stone Cutting Machine Images
